| Contact type |
2 changeover contacts |
| Type of switch contact |
Single contact |
| Contact material |
AgNi |
| Maximum switching voltage |
250 V AC/DC |
| Minimum switching voltage |
12 V (at 10 mA) |
| Min. switching current |
10 mA (at 12 V) |
| Maximum inrush current |
16 A (20 ms) |
| Limiting continuous current |
8 A |
| Interrupting rating (ohmic load) max. |
2000 VA (for 250 V AC) |
| Switching capacity |
1 A (at 24 V, DC13) |
| |
1.5 A (at 24 V, AC15) |
| |
1.5 A (at 120 V, AC15) |
| |
1.5 A (at 240 V, AC15) |
| Motor load according to UL 508 |
1/4 HP, 120 V AC (N/O contact) |
| |
1/2 HP, 240 V AC (N/O contact) |
| |
1/4 HP, 120 V AC (N/C contact) |
| |
1/3 HP, 240 V AC (N/C contact) |
