| Contact type |
1 changeover contact |
| Type of switch contact |
Single contact |
| Contact material |
AgNi |
| Maximum switching voltage |
250 V AC/DC |
| Minimum switching voltage |
12 V (at 10 mA) |
| Min. switching current |
10 mA (at 12 V) |
| Maximum inrush current |
50 A (20 ms) |
| Limiting continuous current |
16 A |
| Interrupting rating (ohmic load) max. |
384 W (at 24 V DC) |
| |
58 W (at 48 V DC) |
| |
48 W (at 60 V DC) |
| |
50 W (at 110 V DC) |
| |
80 W (at 220 V DC) |
| |
4000 VA (for 250 V AC) |
| Switching capacity |
2 A (at 24 V, DC13) |
| |
0.2 A (at 110 V, DC13) |
| |
0.2 A (at 250 V, DC13) |
| |
6 A (at 24 V, AC15) |
| |
6 A (at 120 V, AC15) |
| |
6 A (at 250 V, AC15) |
| Motor load according to UL 508 |
1/2 HP, 120 V AC (N/O contact) |
| |
1 HP, 240 V AC (N/O contact) |
| |
1/3 HP, 120 V AC (N/C contact) |
| |
3/4 HP, 240 V AC (N/C contact) |
| |
1/4 HP, 200 ... 250 V AC |
